Description

4-Piston Billet Aluminum Brake Caliper with Pads – Polished with Clear Anodized Finish

For use with Billet Proof Designs brake caliper mount and other custom mounts.

Features:

• CNC machined from 6061 billet aluminum to eliminate flex and reduce weight.
• Caliper is then Polished and hard coat anodized in a Clear finish.
• Comes with brake pads, ground pin, pin spring, washers and set screw!
• Caliper features brake pads that slide freely on a centerless ground pin to prolong pad life.
• Can be set-up for a front or rear brake application.
• Will require a caliper bracket for most applications (Available Separately).

Dimensions:

• Length = 5″
• Height = 2-7/8″
• Depth (Face to Rear) = 2-3/4″
• Mounting Holes = Clearance for a 3/8” bolt on 3-1/2” centers

Finish:

• Polished with Clear Anodized Finish

Fitment:

• A separate caliper bracket will need to be purchased for specific applications.
• Caliper can also be used with custom builds as long as the surrounding components will accommodate the above listed dimensions.
